Casing Scraper

Product number:KW-CT-11 Casing Scraper is used to remove cement scale, mud, mill scale, rust, paraffin... from the inside walls of casing


We're here to help:
Easy ways to get the answers you need.

  • +86-029-88601839
  • +86-029-88601839
  • kingwell@kingwelloilfield.com
  • Follow Us:
Casing Scraper

The Casing Scraper is used to remove cement scale, mud, mill scale, rust, paraffin, perforation burrs and other substances from the inside walls of casing. This operation produces a smooth inside casing diameter that will assist in a successful down hole operation such as setting packers, bridge plugs, etc.



Technical specification
TYPE I.D.
in
(mm)
Tool Joint
Connection
API
Overall length
ft-in
(mm)
I.D of suitable casing
in(mm)
KW114 1
(25.4)
2-3/8REG 3'
(906)
3-13/16~4-3/32
(97.2~103.9)
KW127 1
(25.4)
NC23 3'3"
(1,000)
4-1/4~4-9/16
(108.6~115.8)
KW140 1
(25.4)
NC26 3'3"
(1,000)
4-5/8~4-15/16
(118.6~125.7)
KW178 1-3/16
(30.0)
3-1/2REG 3'8"
(1,105)
6~6-3/8
(154.8~161.7)
KW245 2-1/4
(57.0)
4-1/2REG 4'5"
(1,340)
8-1/2~8-7/8
(216.8~226.6)
GGQ340 3-1/2
(88.9)
6-5/8REG 4'11"
(1,500)
12-3/6~12-3/4
(315.3~323.0)
