Products > Solid Control
Desander
Product Number: KW-SC-04
We're here to help:
Easy ways to get the answers you need.
- +86-029-88601839
- +86-029-88601839
- kingwell@kingwelloilfield.com
- Follow Us:
KINGWELL Desander Features & Benefits:
Desander is the second class solid control equipment to treat the drilling fluid, which makes separations between 45 and 75 μm. The cones can be 8”, 10”, and 12”. According to customers’ treating capacity requirements, choose different quantity, different size cones.
Features:
1. Polyurethane ( PU ) material or high-chromium cast iron to make desander cones for longer lifespan.
2. Clamp type for easy maintenance.
3. Compact design with small footprint.
4. Flexible fast connection are available for user assembly.
KINGWELL Desander Technical Data:
| Model | KWCS 60 | KWCS 90 | KWCS 120 | KWCS 200 | KWCS 240 | KWCS 320 |
| Treating capacity | 60m³/h | 90m³/h | 120m³/h | 200m³/h | 240m³/h | 320m³/h |
| Cones | 200X2 | 250X1 | 250X1 | 250X2 | 250X2 | 250X3 |
| Working pressure | 0.25~0.45MPa | |||||
| Separation point | 45~75μm | |||||
| Bottom shaker | KWZS series shake | |||||
| Vibration track | Linear or BEM | |||||
| Vibrator motor speed | 1500rpm or 1800rpm | |||||
| Dimension | 1500x1200x1900 | 2300x1700x2200 | 2600X1800X2200 | |||
| Weight | 850kg | 860KG | 860KG | 960KG | 960KG | 1050KG |
| Remark |
8“ cone =30~35m3/h,10” cone=90~120m3/h According to clients’ demand configure cones |
|||||
