Introduction

The drill pipe connects the rig surface equipment with the bottomhole assembly and the bit, both to pump drilling fluid to the bit and to be able to raise, lower and rotate the bottomhole assembly and bit. It`s a major drilling component which connects rotary system, hoisting system, circulation system with drill collar and bit.



Our Drill Pipe Manufacturing capability ranges from 2 3/8" to 6 5/8" Outer Diameter in steel grades E, X, G, S in range 1,
Range2, & Range 3 lengths. Drill Pipes with Special Grade & Length are available on an individual orders.

KINGWELL Non-slip-cut(NSC) Drill Pipe

KINGWELL Non-slip-cut(NSC) Drill Pipe is specially designed for solving problems like the damage to the drill pipe body by the slip cut, the low operation efficiency of double-elevator, and the high labor intensity in the operation of TIH and TOH. This product adds one more shoulder positioned close to the box end than normal API standard drill pipe.

Size range: 4”, 4 1/2”, 5”, 5 1/2”, 5 7/8”, and 6 5/8”



KINGWELL Offshore Casing Landing Pipe

KINGWELL Offshore Casing Landing Pipe is typically used to land heavy casing string in a deep water environment. Designed with sufficient tensile, hoisting and slip-crushing capacity to support the heavy casing string beneath it.

Size range: 5”, 5 1/2”, 5 7/8”, 6 5/8” and 7 5/8”



KINGWELL Arctic Service Drill Pipe

KINGWELL Arctic Service Drill Pipe is a type of propriety drill pipe with capability to perform in extreme cold regions.

Size range: including all API size from 2 3/8 to 6 5/8 inches.



KINGWELL Super High-Strength Drill Pipe

KINGWELL Super High-Strength drill pipes are designed specifically for deep and ultra-deep wells, extended reach drilling (ERD) wells, deep offshore and other critical drilling applications.

Size range: Kingwell high strength drill pipe is available for drill pipe ranging in size from 2 3/8 to 6 5/8 inches.



KINGWELL Slip-protected Drill Pipe

In order to reduce tripping time in the drilling process to improve drilling efficiency, “one elevator one slip” is the general tripping mode. Higher slip crushing capability of the pipe body is required in deep well, extra-deep well and complicated geological conditions. To solve these problems, Kingwell designed and manufactured slip-proof drill pipe, the long thick-walled upset section is designed on the box end.

Size range: 5”, 5 1/2”, 5 7/8”, 6 5/8” and 7 5/8”



KINGWELL Flush-hole Drill Pipe

Kingwell proprietary flush-hole drill pipe is designed to be made-up with the drill pipe body using a special external upset with a large ID. The ID of the tool joint is almost the same as that of the drill pipe body; Decrease annular pressure loss by 20%-50% and improve hydraulic efficiency and drilling speed.

Size range: normally 4 1/2”, 5”, 5 1/2”, 5 7/8”, 6 5/8” and 7 5/8”



KINGWELL HDD Drill Pipe

KINGWELL designed and manufactured the HDD (horizontal and directional drilling) drill pipe meet the large size need, at the same time the rigidity and the thrust also have improved. Special thread design and a guide section adding in the pin thread to prevent the possibility of galling and improve the fatigue capacity, meet the requirement of pipe line horizontal directional drilling engineering.

Size range: normally 5 7/8”, 6 5/8”
